Video System : 4K/60fps, 4K/59.97fps, 4K/50fps, 4K/30fps, 4K/25fps, 4K/29.97fps, 1080P/60fps, 1080P/50fps, 1080I/60fps, 1080I/50fp, 1080P/30fps, 1080P/59.94fps, 1080I/59.94fps, 1080P/29.97fps, 720P/60fps, 720P59.94fps

Sensor

1/2.8”, CMOS, Effective Pixel: 840M

Lens

20x, f=6.25mm ~ 125mm , F1.84 ~ F3.72

Digital Zoom

16X

Minimal Illumination

0.5Lux @ (F1.8, AGC ON)

Shutter

1/30s ~ 1/10000s

White Balance

Auto, Indoor, Outdoor, One Push, Manual, Specified color temperature

Digital Noise Reduction

3D Digital Noise Reduction

Operate System

Windows 7, Windows 8, Windows 10, Mac OS X, Linux, Android

Color System / Compression

YUY2 / H.264 / MJPEG

Video Format

“YUY2 :Max 1080P/30fps

H.264 AVC: Max 2160P/60fps

H.264 SVC: Max 2160P/60fps

MJPEG: max 4K/30fps”

Audio on USB

Support

USB Video Communication Protocol

UVC 1.1~1.5

Video Compression

H.265/H.264/MJPEG

Video Stream

First Stream, Second Stream

Main Stream Resolution

3840×2160, 1920×1080, 1280×720, 1024×576 etc

Sub Stream Resolution

720×576, 720×480, 320×240 etc (*)

Video Bit Rate

32kbps~102400kbps

Frame Rate

50Hz: 1fps~50fps, 60Hz:1fps~60fps

Audio Compression

AAC、G711

Audio Bit Rate

48Kbps, 64Kbps, 96Kbps, 128Kbps
